Precision Machined Solid Shaft for Electric Motors and Gear Drives
Product Details:
| Place of Origin: | China |
| Brand Name: | Zhisheng |
| Model Number: | 20# |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 tons |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Anti rust oil to be applied on material and each rod to be packed in paper sleeve |
| Delivery Time: | 30days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 30tons a day |
|
Detail Information |
|||
| High-frequency Quenching: | HRC50-60 | Surface Hardness: | 800-1150HV |
|---|---|---|---|
| Surface Treatment: | Chromium Plating,medium And High Frequency Induction Hardening,quenching And Tempering,quenching Andtempering+medium And High Frequency Induction Hardening | Salt Spray Test: | Level 9150-300 Hours |
| Weldability: | Good | Packing: | After Rust Prevention Oil Treatment,each Piece Is Wrapped In A Waterproof Paper Tube/wooden Box |
| Quality Certificate: | Provide Product Quality Reports,chromium Plating Thickness Reports,salt Spray Test Reports,etc | Quenching And Tempering Hardness: | HB220-360 |
| Straightness: | ≤0.1mm/m | Surface Roughness: | ≤0.05μm |
| Chromium Plating Thicknes: | 0.02mm-0.50mm | Outer Diameter Tolerance: | Other Customizable Options) |
| Length: | L200-20000mm | Size: | φ20-φ500mm |
| Highlight: | precision machined solid motor shaft,solid shaft for gear drives,electric motor solid shaft |
||
Product Description
Precision Machined Solid Shaft for Electric Motors and Gear Drives
Product Overview
The Precision Machined Solid Shaft is designed for electric motors, reducers, and mechanical drives where accuracy and reliability are critical. Manufactured with advanced CNC machining, it ensures precise fit, stable rotation, and superior mechanical balance.
Product Specifications
| Attribute | Value |
|---|---|
| Material | 45# / 40Cr / 42CrMo |
| Heat Treatment | Quenched and Tempered |
| Hardness | HRC 28-38 |
| Surface Roughness | ≤ 0.03 μm |
| Straightness | ≤ 0.05 mm/m |
| Tensile Strength | ≥ 850 MPa |
| Yield Strength | ≥ 650 MPa |
| Diameter Range | φ10 mm - φ300 mm |
| Length Range | 200 mm - 6000 mm |
| Certification | ISO 9001 / CE / SGS |
Key Features
- Precision CNC machined for tight tolerances
- High fatigue strength and stability
- Excellent alignment and balance for dynamic rotation
- Custom keyways, threads, and splines available
Applications
- Electric motors and reducers
- Industrial gear drives
- Automation and machinery equipment
- Power transmission systems
Customer Benefits
- Smooth operation with minimal vibration
- Reduced wear and maintenance cost
- Fully customizable for OEM designs
Chemical Composition
Want to Know more details about this product
